Scott Scale 26 Rigid - 2022

Scott Scale 26 Rigid
Color: Silver
Please select options Unavailable


The SCOTT Scale 26 Rigid is our truly functional mountain bike for kids. With everything you could want in a mountain bike for kids combined with a classic cool design, you'll be rolling in style.

bike frame with labeled dimensions
Bike Sizes:
A. Reach 368.2mm
B. Stack 520.0mm
C. Standover 670.0mm
D. Effective Top Tube 520.0mm
E. Head Tube Angle 69.0 °
F. Head Tube Length 120.0mm
G. Seat Tube Angle 73.5 °
H. Seat Tube Length 330.0mm
I. Bottom Bracket Height 308.0mm
J. Bottom Bracket Drop -38.0mm
M. Wheelbase 1,022.0mm
O. Chainstay Length 425.0mm
BB To Top Tube Center 285.0mm
Stem Length 45.0mm


Frame JR26 Rigid Disc Alloy 6061, Performance geometry SCOTT dropout, IS
Fork AL-6061 rigid fork, IS
Rims Syncros X-20 Disc, 32H, black
Hubs Front: Formula DC-19-F, QR Disc
Rear: Formula DC-25-8-R, QR Disc
Spokes 15g, stainless, black
Tires Front: Kenda K1227 Booster, 26x2.4", 30TPI
Rear: Kenda K1227 Booster, 26x2.4", 30TPI
Bottom Bracket Feimin, BB68, cartridge, square taper
Crankset Prowheel 36-22T w/CG
Shifters Shimano FD-M315-TS, 34.9mm
Front Derailleur Shimano FD-M315-TS, 34.9mm
Rear Derailleur Shimano Tourney RD-TX800 16 Speed
Cassette/Freewheel SunRace CSM55 8AV, 11-34T
Chain KMC Z8.3
Brakes Tektro HD-M276, Hydr. Disc 160F/160R rotor, short reach lever
Brake Levers Tektro HD-M276
Handlebars HL MTB-AL-312BT, 640mm, black, 12mm rise Syncros Youth 115
Stem HL TDS-C342, 10°, 31.8, Black
Headset Feimin FP-H807, 1 1/8" Semi Int.
Seatpost Alloy, 31.6mm, 350mm
Saddle Syncros Future Pro
Pedals Feimin FP-803, w/Reflector

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Silver 192820614090 286614222 286614222
