Diamondback Release 3 - 2021

Diamondback Release 3
  • Color: Curry Yellow Matte
  • Color: Curry Yellow Matte
$3,999.99
Color:
Curry Yellow Matte
Please select options
This item is not permitted to be shipped, however it can be purchased online and picked up at your convenience.

Details

A privateer is a top-level rider who hits the trails without the benefit of a fancy sponsorship deal. Their ideal rig? A blue-collar machine that doesn't skimp on performance. That sums up the Release 3 perfectly. The heart of the bike is our artfully shaped and butted aluminum frame and brisk-pedaling Level Link suspension. A Fox 34 Performance Float 150mm travel fork and Fox Float DPX2 rear shock work in perfect tandem to obliterate tooth-rattling hits on even the longest of descents. Shimano's reliable XT 12-speed drivetrain components offer up seasons of accurate shifts and Shimano XT hydraulic disc brakes continue to impress with their excellent balance of power and finesse. Other brag-worthy components include our burly Blanchard tubeless-ready wheelset, Maxxis Minion DHF/DHR tires, and a KS LEV Si dropper post. The Release 3... pro-caliber quality for those of us with day jobs.

Specs

Frame Release 27.5, 130mm Travel, Level Link Suspension Platform, Hydroformed Tubing, ISCG-05 Tabs, Boost 148x12mm Maxle Drop Out, 1.5" Tapered Headtube
Fork Fox 34 Performance Float, 27.5", 150mm Travel, Grip 3 Position Dampener, Rebound Adjust, 1.5" Tapered Steerer, 110x15mm Thru-axle
Rear Shock Fox Performance Float DPX2, 3 Position Lever, LV EVOL, 200x57mm, 22.2mm Eyelet Width
Rims Diamondback Blanchard 28R, Tubeless ready, 32h
Spokes 14g Stainless Steel
Tires Front: Maxxis Minion DHF 27.5x2.3" EXO, TLR, Folding
Rear: Maxxis Minion DHR 27.5x2.3" EXO, TLR, Folding
Bottom Bracket Raceface Outboard Bearing
Crankset Shimano XT M8100, 32T
Shifters Shimano XT M8100, 12 Speed
Rear Derailleur Shimano XT M8100 Shadow Plus, 12 Speed SGS
Cassette/Freewheel Shimano XT M8100 Cassette, 12 Speed, 10-51T
Chain Shimano XT M8100, 12 Speed
Brakes Shimano XT M8100, w/180mm Front /180mm Rear, RT800 Rotors
Brake Levers Shimano XT M8100
Handlebars DB35 Aluminum 780mm Wide, 15mm Rise, 35mm Bar Bore
Tape/Grips Ergon GE10 Evo Lock-On
Stem DB35 Aluminum 40mm Reach, 35mm Bar Bore
Headset FSA No. 57 Sealed Cartridge
Seatpost KS LEV SI Internal Dropper, 31.6mm w/ Southpaw Remote
Saddle WTB Volt Race
Pedals DB CNC Platform, Sealed Cartridge Bearing w/Replaceable Pins
Accessories & Extras Tool Kit, DB Shock Pump, DB Mud Guard, Chainstay Protector, Carbon Paste

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Curry Yellow Matte / Small 791964593744 02-0310161 02-0310161
Curry Yellow Matte / X-Large 791964593775 02-0310164 02-0310164
